Features
1, integrating the optometry/corneal curvature measurement function.
2, leading optical technology, measuring good consistency and ensure measured data accurate and reliable.
3, the most advanced image processing technology, make the image more clear, measurement speed is faster.
4, Humanized auxiliary focusing function, is the focus to capture more quickly.
Specifications
Measurement mode | K&R mode | Measurement of diopter and corneal curvature |
REF mode | Diopter measurement | |
KER mode | Corneal curvature measurement | |
CLBC mode | Measuring the curvature of contact lenses | |
Refractive measurement | Vertex distance (VD) | 0mm，12.0mm，13.75mm，15mm |
Spherical mirror | （－25.00~+22.00）D(0.12/0.25D）（VD=12mm) | |
Axial | 1° ~180° （steps1°） | |
Interpupillary distance range | 45~85mm(accuracy0.5mm） | |
Minimum pupil diameter measurement | Ф2.0mm | |
As the standard | Automatic cloud chart | |
Corneal measurement | Corneal curvature radius | 5~10mm（0.01mm steps） |
Corneal diopter | （33.00~67.00）D（0.12/0.25D Steps） | |
Corneal astigmatism | （0.00~－15.00）D（0.12/0.25D steps） | |
Axial | 1° ~180°（steps1°） | |
Corneal diameter | 2.0~12.00mm | |
Product specification | Monitor | 5.7 inch TFT color LCD |
Built-in printer | Imported thermal printer | |
Battery Saving Mode | 5 minutes without operation automatic screen saver | |
Power Supply | AC110~240V；50/60HZ | |
Size / weight | 275(W)*475(D)*435—465(H)mm/18kg |
