Features
Processing of different materials lenses (glass GL, resin CR PC lens) to select a different wheel according to the lens material (GL / CR), not only saving dual effort.
Size Adjustment (+, -) when working properly or appear damaged wheel can be adjusted automatically by a computer control keys,accurate to 0.05mm lens size can increase or decrease.
Effective use of grinding wheels, DIA is to extend the service life of the grinding wheel, grinding to do about mobile roughing,effective use of wheel width.
STOP stop grinding process needs time to pause and resume using in situ.Automatic lens system automatically clip clip lenses, computer gear selection pressure 1-3, arbitrary adjustments.
Specifications
Place of Origin | Shenzhen China |
Brand Name | AIST |
Model Number | SJM-2008 |
Disc diameter | 22-80mm |
Clamping force of grinding disc | 0.45-1.10mpa (adjustable in three gears) |
Diameter of grinding wheel | 100mm |
Linear speed of grinding wheel | 16.7mls |
Operating voltage | 110-240V,50-60Hz |
Power consumption | 400VA |
Working environment temperature | 5℃-40℃ |
External dimensions | 510×410×470mm |
Weight | 41 kg |
Water supply system | Circulating water supply and direct water supply |
