Features
●With functions of diagnosis, treatment, simultaneous viewing, syncretic viewing, solid viewing, and afterimage.
●Equipped with a pair of Haidingers Brush and 20 pairs of pictures with different angle.
●Advanced semi-transparent and semi- reflecting viewfinder is convenient for the surgeon to observe.
●Advanced LED luminophor has even illumination, low heat and long service life.
●Pictures designed by new technology are anti-broken and has long service life.
●Manual or automatical coruscation with accurate frequency are at surgeon' s option.
●Optional pictures for quantitative measuring of solid acutance (40 "~1000 ")
Specifications
Magnification | 1.65X |
Diameter of Field Red | > 56mm |
Red light | λ=640mm coruscation system |
Left and right tubes rotate around erect axis | Converging 50 degree diverging 40 degree |
Left and right tubes rotate around horizontal axis | ±30 degree |
Pictures of left and right can be moved up and down according optical axis | ±10 degree |
Pictures of left and right rotate around optical axis | ±20 degree |
Adjustable range of interpupillary distance | 45~75mm |
Darkroom illumination | LED bulb with symmetry design. |
Adjustable Haidingers Brush | 50-100round/ minute |
Coruscation form | manual or automatic |
Automatic coruscation frequency | ten-step, 30-300times/minute |
Range of automatic coruscation(each cycle) | 1/4 on 3/4 off, 1/2on 1/2 off, 3/4 on 1/4 off |
Power supply | AC220V 50Hz |
Power consumption | 40VA |
Type of automatic coruscation | l The left and right can be turned on or off at the same time. l The left and right can be turned on or off alternatively. l One on and the other off l One on or off while the other can be turned on or off |
