Features
1. Assistant microscope can be rotated to opponent microscope.
2. Internal beam splitter can be connected with teaching tube and CCD system.
3. Equipped with three different objective lenses (f200/f250/f300) and applicable in ophthalmic surgery, orthopedic surgery and hand surgery.
4. Oblique illumination can also be used as slit illumination and slit width is adjustable.
Specifications
Objective Focus | f=200mm |
Working Distance | 170mm |
Magnification for Main Microscope | 4.6x ~27x , motorized and manual control, continuous magnification |
Magnification for Assistant Microscope | 6x, 10x, 16x |
Diameter of Field | 46mm ~8.5mm |
Adjustable Diopter | ±6D |
Adjustable Range of Pupil Distance | 55mm ~ 75mm (main microscope is 45mm – 80mm) |
Maximal Resolution | 119LP/m |
Focus for Assistant Microscope | ≥ 30mm |
Illumination Source | 12V/100W Cold Refraction Halogen Lamp. For medical use |
Illumination Type | 6°+ 0° Coaxial illumination of cold light source, 26°oblique illumination |
Coaxial Illumination | ≥60000Lx, 1-9 Level; panel Operated |
Oblique Illumination | ≥60000Lx, 1-9 Level; panel Operated |
Reaching Radius of Arm | 1230mm |
Adjustable Vertical Range | 880mm ~ 1420mm |
Fine Focus Speed and Range | ≤ 2mm/s, 50mm |
Speed for X/Y and Range | ≤ 2mm/s, 50mm x 50mm |
Input Voltage | AC 220V ± 22V /50HZ ±1HZ, AC 110V ±11V/60HZ±1Hz |
Power | 170VA |
Fuse | AC 250V T3.15A(51S-0.32H), AC125V T6.3A (51S-063L) |
Electrical Safety Standard | Executive standard: GB 9706.1-2007, Class I |
Packing Volume | 0.756cbm, 5 cartons |
Total Gross Weight | 215kg |
