Features

MACULA
LSO:Equipped with LSO(Line Scanning Ophthalmoscopy)MOcean 3000 provides simultaneously high quality fundus imaging,which is easy
for physicians to localize the lesion.
MACULA: Macula HD line: High definition OCT imaging reveals small lesions, OCT scan length can be switched between 6mm and 12mm.
Macula Six-line Radial:Having a glimpse of the retina with HD imaging and quick data analysis
Software Analysis:Retinal thickness analysis, Ganglion cell analysis, High definition OCT imaging with 5 images averaging.
Macula Cube: A point-by-point assessment of retinal thickness with a 500 x100 dense cube
Software Analysis:Retinal thickness analysis,Progression analysis,3D view,En-face analysis.
GLAUCOMA
For comprehensive glaucoma analysis. MOcean 3000/3000 Plus offers two scan modes: glaucoma cube scan in macular area and glaucoma
cube scan in disc area. Evenly distributed sampling rate with 200 x200 A-scans provides reliable information for early glaucoma
detection and management.
Glaucoma (Macular): Software Analysis:Ganglion cell analysis, Progression analysis.
Glaucoma(Disc): Software Analysis:RNFL analysis, Cup-disk analysis,Calculation circle and circle scan tomogram,Progression
analysis,OU comparative analysis.
Informative Report: OU comparative analysis, Progression analysis report.
ANTERIOR SEGMENT
Anterior HD line:High-definition OCT imaging of the cornea enables localization of the Bowman’s layer, the interface between
corneal stroma and and epithelium, Anterior Chamber Angle,Manual measurement is available.
Anterior Six-line Radial:The anterior segment scanning through 6 radial lines of equal length can be used to measure the central
corneal thickness, Software Analysis, Corneal pachymetry,Manual measurement.
PERMIUM FUNCTIONS
En-face Analysis:En-face OCT provides ability to precisely localize lesions within specific subretinal layers.
Choroid View
IS/OS-Ellipsoid View
Mid-Retina View
VRI View
3D En-face View
Network System: Remote Analysis System:Moptim provides a remote viewer software for displaying,enhancing,analyzing and saving
digital images obtained with MOcaen 3000/3000plus.
Remote Diagnosis System: Customer scan are reviewed remotely by specialists at Big Picture Eye Health for over 45 eye pathologies.
The software immediately generates a customer report, including educational content and specialist referral if needed.
This optional module,which is developed and operated by Big picture Eye Health, can be connected to MOcean 3000 seamlessly.

Specifications
