Product Description
Features
1.Professional image analyzing, processing and management system; professional optics with CCD
2.Professional optics with CCD
3.Support for imaging & refractive devices
4.Advanced image processing tools and management system
5.Advanced query possibilities on database
6.It is possible to use previously obtained data as a starting point for further operations.
7.The windows for captures and for viewing images are TAB based,which provide a good overview
8.Most important feature is the creation of advanced queries in the patient database.
9.Professional software with video function
10.Background illumination system;
11.Flash function
12.DICOM compliant
Specifications
| Model | SLM-3ER |
| Microscope Type | Galileo Parallel |
| Magnification Change Way | Drum Five Magnifications |
| Digital System | Nikon D 5200 with high definition DSLR24.1 Mega Pixels |
| Background Illumination | With |
| Total Magnifications | 6x,10x,16x,25,40x |
| Eyepiece | 12.5x |
| Diopter Adjustment | -5D~+5D |
| Slit Width | 0-14mm continuous |
| Slit Height | 1-14mm continuous |
| Slit Angle | 0-180°adjustable |
| Light Spot Diameter | 0.2,1,2,5,10,14mm |
| Filters | Heat Absorption, Yellow, Redfree (green), Cobalt Blue |
| Input Voltage | 110V/220V (±10%) |
| Fixation | Red LED |
| Illumination Bulb | LED |
| Light Source | High Light Source |
