Features:
1.The operating board which can horizontally rotate 90° uses quality environmental protection materials that is high-temperature endurable, abrasion proof, corrosion resistance, solid and bearable. It can provide power input.
2. The design of the hand-operated rocker is more human because the rocker can randomly swing up and down,
left and right to the best position, making the optometrist’s operation more convenient and the subject’s eyes
more comfortable, improving the satisfaction of the optometrist and the subject.
3.The comfortable and beautiful electric chair has large lifting range, low noise and automatic inhibiting function,
it runs safely and steadily, making the subject and the operator feel quick and easy when use this instrument.
Specifications:
TR-510D | ||
Mechanical Parameters
| Angle of rotation for rocker | ±30° |
Table size | 840mm×405mm | |
Angle of rotation for table | 90° | |
Chair height adjustment range | 150mm~200mm | |
Loading for chair | 70kg~150kg | |
Electrical Parameters
| Input voltage | 110V/220V AC 50Hz～60Hz |
Engine power | 55W 24V DC | |
Light | 16W 110V/220V AC | |
Fuse | 5A 250V AC | |
No load power | 1W | |
Pressure test | 2KV | |
Main wire | 10A 250V | |
Working mode | S1 | |
Working temperature | -－30℃~＋50℃ | |
Relative humidity | less than 90% | |
Installation Dimension
| Figure size | 1150mm×865mm×2030mm |
Weight | 150kgs | |
