Specification
Range:
Sphere Lens 0 to ±35D (Increments 0.01D/0.06D/0.12D/0.25D)
Range: | Increments | |
<0D, ≥-5D | >0D, ≤+5D | ±0.06 |
<-5D,≥-10D | >+5D,≤+10D | ±0.09 |
<-10D,≥-15D | >+10D,≤+15D | ±0.12 |
<-15D,≥-20D | >+15D,≤+20D | ±0.18 |
<-20D,≥-35D | >+20D,≤+35D | ±0.25 |
Cylinder Lens: 0 to±10D (Increments 0.01D/0.06D/0.12D/0.25D)
Axis: 0°to 180 (Increments 1°)
ADD: 0 to 10D (Increments 0.01D/0.06D/0.12D/0.25D)
Prism: 0 to 15A (0.01△)
Prism Range Increments
>0△, ≤5△ 0.1△
>5A, ≤15△ 0.2△
Cylinder Mode : +,+/-,-
Prim Mode: cartesian coordinates H: l,o .v: u,D P-B;polar coordinates
mm: X and Y in mm
Increments: 0.01D/0.06D/0.12D/0.25D
PD Measurement
Measure single vision lens, bifocal lens, trifocal lens and progressive lens, etc.
UV/Blue Light Transmissivity Detection
CL Lens Accessible
Reflect Ratio: >10% Reflect Ratio while Diopter over +/-10D > 20%
Contact lens: 0 to ±25D, BC 6.00 to 9.00
Monitor: 7.0 Inch HD Touch Screen
Menu: humanized Design and Easy Operation
Lens Diameter Capacity: 20mm-100mm
Voltage: AC 100 (±10% ) -240 ( ±10%)v 50/60Hz 40VA
Power: 40w
Weight: 6.8kgs
Machine Size:55omm*350mm*350mm(L*W*H)
Storage Condition
a.Temperature:5-40℃ (In use)-20-60°c( Storage/Transportation)
1. Humidity: 30-85% 10-95% (Storage/Transportation)
2. Air Pressure: 700-1060hpa
3. Altitude: up to 2000m
4. Others: No Harmful Dust or Smog
