Features
1. Adjustable LCD display screen:Tilt color screen provides you with clear view from any position such as
sitting and standing;
2. Sensitive touch LCD display screen:You just touch the screen to finish your measurement.The operation
could be easier and more convenient.
3. Measurement screen:Easy to use with recognizable icons;The JD-2000 series provide a user-friendly
graphical interface for an immediate understanding.
4. Progressive measurement:A graph helps the operator to improve accuracy and sped in the measurement
of near and far vision.
5. Automatic recognition of single and progress lens
6. High Speed UV measurement: Just hold the lens through the sensor, the display will easily indicate the
UV measurement by the progress bar.
7. Built-in thermal printer:Quick data print with built-in printer. Easy to reload printing paper.
Specifications
| Range of Measurement | |
| Sphere | 0~+- 25D, 0.01/0.12/0.25D step; |
| Cylinder | 0~ +-9.9 D 0.01/0.12/0.25D step |
| Axis | 0-180 ° (1 ° step) |
| Add | 0-9.99 D 0.01/0.12/0.25D step |
| Prism degree | 0-15 D 0.01/0.12/0.25D step |
| Measurement Mode | |
| Cylinder | +, +/-, - |
| Prism | X-Y, P-B |
| Contact Lens | soft/hard; |
| Measuring mode | Single/progressive/automatic recognition |
| Specifications | |
| Diameter of lens | 20-108mm; |
| PD | 40-90mm, 0.5mm step |
| Speed of measurement | 0.1s; |
| Display | 7'' TFT LCD |
| Printer | JD-2000: Thermal Printer, JD-2000B: No printer; |
| Weight | 6kg |
| Power supply | 100-240V, 50-60HZ |
